2861470 | Phoenix Contact

Output terminal for inline station, Outputs: 2, (W x H x D) 12.2 x 119.8 x 71.5 mm, 2861470

Order No.: 64P8946
EAN: 4017918894399
MPN:
2861470
IB IL 24 DO 2-PAC
Series: IB IL
Phoenix Contact
2861470 Phoenix Contact Digital modules
Image may differ
Unit Price (€ / pc.)
97.5086 € *
Available: 0 pcs.
Available in 10 days: 89 pcs.
Leadtime: 2 Weeks **
Total Price:
97.51 € *
*incl. VAT plus shipping costs
**Subject to prior sale
1 pcs.
97.5086 €

Digital module, 2861470, Phoenix Contact

Inline, Digital output terminal, Digital outputs: 2, 24 VDC, Connection technology: 4-conductor, Transmission speed in the local bus: 500 kbps, Degree of protection: IP20, including Inline connector and labeling field.

Features

  • Nominal current per output: 500 mA
  • Total current of the terminal: 1 A
  • Short-circuit and overload-protected outputs
  • Diagnostic and status indicators
Technical specifications
Number of digital outputs 2
Version output terminal
Width 12.2 mm
Suitable for inline station
Height 119.8 mm
Assembly DIN rail
Depth 71.5 mm
Logistics
Country of origin DE
Customs tariff number 85389091
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free No
Substance description Lead
