1135294 | Phoenix Contact
PCB terminal, 3 pole, pitch 5 mm, AWG 24-12, 32 A, push-in spring connection, black, 1135294
Unit Price (€ / pc.)
1.3804 € *
Available: 0 pcs.
Leadtime: On Request **
PCB terminal block, 1135294, Phoenix Contact
PCB terminal block, nominal current: 32 A, rated voltage (III/2): 400 V, nominal cross section: 4 mm², number of rows: 1, number of positions per row: 3, pitch: 5 mm, connection method: Push-in spring connection, mounting: THR soldering, conductor/PCB connection direction: 0 °, color: black, Pin layout: Linear pinning, Solder pin [P]: 2.6 mm, number of solder pins per potential: 2.
Features
- Time saving push-in connection, tools not required
- Defined contact force ensures that contact remains stable over the long term
- Intuitive operation due to color-coded actuating push button
- Operation and conductor connection from one direction enable integration into front of device
- Designed for integration into the SMT soldering process
Technical specifications
| Anschluss | Push-in-Federanschluss | |
| AWG-Leiterquerschnitt | AWG 24-12 | |
| Breite | 15.8 mm | |
| Farbe | schwarz | |
| Höhe | 15.4 mm | |
| Kontaktabstand | RM 5 | |
| Leiterquerschnitt | 0,2-4,0 mm² | |
| Nennspannung | 400 V | |
| Nennstrom | 32 A | |
| Polzahl | 3-polig | |
| Rastermaß | 5 mm | |
| Tiefe | 19.15 mm |
Download
Logistics
| Ursprungsland | PL |
| Zolltarifnummer | 85369010 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | No |
