1700389 | Phoenix Contact
PCB terminal, 7 pole, pitch 3.81 mm, AWG 26-18, 12 A, spring-clamp connection, green, 1700389
Unit Price (€ / pc.)
4.6767 € *
Available: 0 pcs.
Available in 10 days: 5 pcs.
Leadtime: 1 Week **
Total Price:
4.68 € *
Price list
Quantity
Price per unit*
1 pcs.
4.6767 €
10 pcs.
4.3078 €
50 pcs.
3.9151 €
100 pcs.
3.5224 €
*incl. VAT plus shipping costs
**Subject to prior sale
PCB terminal, 1700389, Phoenix Contact
PCB terminal block, nominal current: 12 A, rated voltage (III/2): 160 V, nominal cross section: 1 mm², number of potentials: 7, number of rows: 1, number of positions per row: 7, pitch: 3.81 mm, connection method: push-in spring connection, conductor/PCB connection direction: 90 °, color: green, pin layout: linear double pinning, solder pin: 3.4 mm, number of solder pins per potential: 2.
Features
- Time saving push-in connection, tools not required
- Defined contact force ensures that contact remains stable over the long term
- Intuitive use through colour coded actuation lever
- Two solder pins reduce the mechanical strain on the soldering spots
- The latching on the side enables various numbers of positions to be combined
Technical specifications
| Anschluss | Federklemmanschluss | |
| AWG-Leiterquerschnitt | AWG 26-18 | |
| Breite | 29.17 mm | |
| Farbe | grün | |
| Höhe | 17.1 mm | |
| Leiterquerschnitt | 0,14-1,0 mm² | |
| Nennspannung | 160 V | |
| Nennstrom | 12 A | |
| Polzahl | 7-polig | |
| Rastermaß | 3.81 mm |
Download
Logistics
| Ursprungsland | GR |
| Zolltarifnummer | 85369010 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
