1891195 | Phoenix Contact
PCB terminal, 15 pole, pitch 3.5 mm, AWG 26-20, 4 A, spring-clamp connection, green, 1891195
Unit Price (€ / pc.)
4.2245 € *
Available: 0 pcs.
Leadtime: 8 Weeks **
Total Price:
4.22 € *
Price list
Quantity
Price per unit*
1 pcs.
4.2245 €
10 pcs.
3.8913 €
50 pcs.
3.5343 €
100 pcs.
3.1773 €
*incl. VAT plus shipping costs
**Subject to prior sale
PCB terminal, 1891195, Phoenix Contact
PCB terminal block, nominal current: 4 A, rated voltage (III/2): 250 V, nominal cross section: 0.5 mm², number of potentials: 15, number of rows: 1, number of positions per row: 15, pitch: 3.5 mm, connection method: push-in spring connection, conductor/PCB connection direction: 90 °, color: green, pin layout: linear pinning, solder pin: 3.5 mm, number of solder pins per potential: 1.
Features
- Time saving push-in connection, tools not required
- Defined contact force ensures that contact remains stable over the long term
- Intuitive use through colour coded actuation lever
- Vertical connection enables multi-row arrangement on the PCB
Technical specifications
| Connection | spring-clamp connection | |
| AWG cross-section | AWG 26-20 | |
| Width | 53 mm | |
| Colour | green | |
| Height | 13 mm | |
| Cable cross-section | 0.12-0.5 mm² | |
| Rated voltage | 250 V | |
| Rated current | 4 A | |
| Pin number | 15 pole | |
| Grid | 3.5 mm |
Download
Logistics
| Country of origin | IN |
| Customs tariff number | 85369010 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
