1984358 | Phoenix Contact
PCB terminal, 6 pole, pitch 3.5 mm, AWG 26-16, 8 A, screw connection, green, 1984358
Unit Price (€ / pc.)
2.2015 € *
Available: 0 pcs.
Available in 10 days: 142 pcs.
Leadtime: 1 Week **
PCB terminal, 1984358, Phoenix Contact
PCB connector, nominal cross section: 1.5 mm², color: green, nominal current: 8 A, rated voltage (III/2): 200 V, contact surface: tin, type of contact: female connector, number of potentials: 6, number of rows: 1, number of positions: 9, number of connections: 9, pitch: 3.5 mm, connection method: screw connection with wire protector, conductor/PCB connection direction: 0 °, plug-in system: COMBICON PST 1,0, locking: without, mounting: without.
Features
- Low temperature rise, thanks to maximum contact force
- Allows connection of two conductors
- High terminal block capacity thanks to rectangular terminal block space
- The latching on the side enables various numbers of positions to be combined
Technical specifications
| Anschluss | Schraubanschluss | |
| AWG-Leiterquerschnitt | AWG 26-16 | |
| Breite | 21 mm | |
| Farbe | grün | |
| Höhe | 11 mm | |
| Leiterquerschnitt | 0,2-1,5 mm² | |
| Nennspannung | 200 V | |
| Nennstrom | 8 A | |
| Polzahl | 6-polig | |
| Rastermaß | 3.5 mm |
Download
Logistics
| Ursprungsland | CN |
| Zolltarifnummer | 85366990 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | No |
| Substanz Beschreibung | Blei |
