1434866 | Phoenix Contact
Plug, M12, 4 pole, solder pins, screw locking, straight, 1434866
Unit Price (€ / pc.)
19.8135 € *
Available: 0 pcs.
Available in 10 days: 70 pcs.
Leadtime: 1 Week **
Total Price:
19.81 € *
Price list
Quantity
Price per unit*
1 pcs.
19.8135 €
10 pcs.
18.2308 €
50 pcs.
16.7790 €
100 pcs.
15.2677 €
*incl. VAT plus shipping costs
**Subject to prior sale
Sensor-actuator connector, 1434866, Phoenix Contact
Bus system flush-type connector, Ethernet, 4-pole, M12, shielded, rear/screw mounting, with angled solder connection.
Features
- Unshielded
- D-coded
- Overvoltage category: II
- Pollution degree: 3
- Degree of protection: IP67
Technical specifications
| Version | plug | |
| Thread size | M12 | |
| Coding | D | |
| Contact connection | solder pins | |
| contact surface | gold-plated | |
| Assembly | rear/screw mounting | |
| Orientation | straight | |
| Pin number | 4 pole | |
| Degree of protection (IP) | IP67 | |
| Type of locking | screw locking |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85369010 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Lead |
