1440711 | Phoenix Contact

Socket, M12, 4 pole, solder pins, SPEEDCON locking, straight, 1440711

Order No.: 61P9664
EAN: 4046356554053
MPN:
1440711
VS-EC-MSDB SH SCO
Series: VS-EC
Phoenix Contact
1440711 Phoenix Contact Sensor-Actuator Connectors
Image may differ
Unit Price (€ / pc.)
14.5656 € *
Available: 0 pcs.
Available in 10 days: 905 pcs.
Leadtime: 1 Week **
Total Price:
14.57 € *
*incl. VAT plus shipping costs
**Subject to prior sale
1 pcs.
14.5656 €

Sensor-actuator connector, 1440711, Phoenix Contact

Sensor/actuator flush-type plug, Mini-B USB, M12 SPEEDCON, with straight solder connection.

Features

  • Easy PCB assembly
  • Fast locking system
  • Shielded
  • Flammability rating according to UL 94: V0
  • Degree of protection: IP65
Technical specifications
Version socket
Thread size M12
Contact connection solder pins
contact surface gold-plated
Assembly front mounting
Orientation straight
Pin number 4 pole
Degree of protection (IP) IP67
Type of locking SPEEDCON locking
Logistics
Country of origin DE
Customs tariff number 85366990
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free No
Substance description Lead
