1620125 | Phoenix Contact
Socket, M23, 17 pole, solder connection, SPEEDCON locking, straight, 1620125
Unit Price (€ / pc.)
34.4743 € *
Available: 0 pcs.
Leadtime: 4 Weeks **
Coupler connector, 1620125, Phoenix Contact
Coupler connector, CA, straight, for standard and SPEEDCON interlock, M23, No. of pole: 17, Direction of rotation: Standard, type of contact: Socket, Solder connection, cable diameter range: 4 mm - 6 mm.
Features
- Shielded
- Connector for flexible on-site assembly
- Consistent EMC protection for reliable transmission of signals
- Solder connection: proven connection technology for various litz wires
- Circular connector
Technical specifications
| Version | Buchse | |
| Thread size | M23 | |
| Coding | N | |
| Contact connection | Lötanschluss | |
| contact surface | vernickelt/vergoldet | |
| Assembly | Kabelmontage | |
| Orientation | gerade | |
| Pin number | 17-polig | |
| Degree of protection (IP) | IP67 | |
| Type of locking | SPEEDCON-Verriegelung |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Blei |
