3076032 | Phoenix Contact

Protective conductor terminal, screw connection, 0.2-4.0 mm², 21 A, 6 kV, gray, 3076032

Order No.: 60P5857
EAN: 4046356644020
MPN:
3076032
UTI 2,5-PE/L/NTB
Series: UTI
3076032 Phoenix Contact Series Terminals
Image may differ
Unit Price (€ / pc.)
4.7957 € *
Available: 0 pcs.
Available in 10 days: 700 pcs.
Leadtime: 1 Week **
Total Price:
4.80 € *
*incl. VAT plus shipping costs
**Subject to prior sale
1 pcs.
4.7957 €

Installation ground terminal block, 3076032, Phoenix Contact

Installation ground terminal block, rated voltage: 400 V, nominal current: 21 A, Screw connection, Rated cross section: 4 mm², cross section: 0.2 mm²  - 4 mm², Screw connection, Rated cross section: 4 mm², cross section: 0.2 mm²  - 4 mm², mounting type: NS 35/7,5, NS 35/15, color: gray.

Features

  • The installation terminal block features a particularly low-profile design and is suitable for wiring in flat installation distributors
Technical specifications
Anschluss Schraubanschluss
Ausführung Schutzleiterklemme
AWG-Leiterquerschnitt AWG 24 bis 12
Bemessungsspannung 400 V
Bemessungsstoßspannung 6 kV
Breite 5.2 mm
Farbe grau
Höhe 51.5 mm
Länge 93.5 mm
Leiterquerschnitt 0,2-4,0 mm²
Nennstrom 21 A
Verschmutzungsgrad 3
Logistics
Ursprungsland DE
Zolltarifnummer 85369010
Compliance
RoHS konform Yes
Stand der RoHS-Richtlinie 3/31/15
SVHC frei Yes
