3247975 | Phoenix Contact

Bolt terminal, bolt connection, 2.5-70 mm², 1 pole, 192 A, 8 kV, yellow/black, 3247975

Order No.: 60P4040
EAN: 4046356725095
MPN:
3247975
RBO 8-FE-HC
Series: RBO
3247975 Phoenix Contact Series Terminals Image 1
3247975 Phoenix Contact Series Terminals Image 2
Image may differ
Unit Price (€ / pc.)
21.1701 € *
Available: 0 pcs.
Available in 10 days: 106 pcs.
Leadtime: 1 Week **
Total Price:
21.17 € *
Price list
Quantity
Price per unit*
1 pcs.
21.1701 €
10 pcs.
19.4803 €
50 pcs.
17.9214 €
100 pcs.
16.3030 €
*incl. VAT plus shipping costs
**Subject to prior sale

Bolt connection terminal block, 3247975, Phoenix Contact

Bolt connection terminal block, rated voltage: 1500 V, nominal current: 192 A, connection method: Bolt connection, 1 level, Rated cross section: 70 mm², mounting type: NS 35/7,5, NS 35/15, direct screw connection, color: black/yellow.

Features

  • Mounting on standard DIN rails or directly in control boxes
  • Tested for railway applications
Technical specifications
Anschluss Bolzenanschluss
Anzahl der Klemmstellen 2
Ausführung Bolzenklemme
Bemessungsspannung 1500 V
Bemessungsstoßspannung 8 kV
Breite 29 mm
Farbe gelb/schwarz
Höhe 66 mm
Länge 184 mm
Leiterquerschnitt 2,5-70 mm²
Nennstrom 192 A
Polzahl 1-polig
Verschmutzungsgrad 3
Logistics
Ursprungsland CN
Zolltarifnummer 85369010
Compliance
RoHS konform Yes
Stand der RoHS-Richtlinie 3/31/15
SVHC frei Yes
