1708744 | Phoenix Contact
Feed through terminal, 1 pole, 10-50 mm², clamping points: 2, gray, cable connection, 150 A, 1708744
Unit Price (€ / pc.)
17.6477 € *
Available: 0 pcs.
Leadtime: 7 Weeks **
Total Price:
17.65 € *
Price list
Quantity
Price per unit*
1 pcs.
17.6477 €
10 pcs.
16.2197 €
50 pcs.
14.7679 €
100 pcs.
13.2923 €
*incl. VAT plus shipping costs
**Subject to prior sale
Terminal block, 1708744, Phoenix Contact
Panel feed-through terminal block, connection method: T-LOX knee lever connection, cable lug connection, number of positions: 1, load current: 150 A, cross section: 10 mm² - 50 mm², connection direction of the conductor to plug-in direction: 0 °, width: 38 mm.
Features
- Lever actuation enables time-saving and smooth connection of large conductors
- Defined contact force ensures that contact remains stable over the long term
- 90° open clamping space allows the conductor to be conveniently swiveled
- Quick, tool-free mounting on the housing wall using a fixing wedge
Technical specifications
| Version | Durchführungsklemme | |
| Pin number | 1-polig | |
| Cable cross-section | 10-50 mm² | |
| Number of terminals | 2 | |
| Colour | grau | |
| Connection | Kabelanschluss | |
| Rated current | 150 A | |
| AWG cross-section | AWG 8-1 |
Download
Logistics
| Country of origin | PL |
| Customs tariff number | 85369010 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
