MS-215-5-3-0500 | PIC GmbH

Reed switche, ABS, 1 Form A (N/O), 10 W, 200 V (DC), 0.3 A, MS-215-5-3-0500

Order No.: 30G4763
EAN: 4099889449136
MPN:
MS-215-5-3-0500
MS-215-5-3-0500 PIC GmbH Proximity Switches, Reed switches Image 1
MS-215-5-3-0500 PIC GmbH Proximity Switches, Reed switches Image 2
Image may differ
Unit Price (€ / pc.)
2.7965 € *
Available: 0 pcs.
Leadtime: 14 Weeks **
Total Price:
1,398.25 € *
*incl. VAT plus shipping costs
**Subject to prior sale
500 pcs.
2.7965 €

Reed sensor, MS-215-5-3-0500, PIC GmbH

The MS-215-5-3-0500 is a mains voltage reed sensor with different magnetic sensitivity ranges.

Applications

  • Position control
  • Non touch switching
Technical specifications
Anschluss Litzen
Ausführung ABS
Durchmesser 6 mm
Länge 25.7 mm
Produkt-Art Reedsensor
Schaltfunktion 1 Schließer
Schaltleistung 10 W
Schaltspannung (AC) 260 V
Schaltspannung (DC) 200 V
Schaltstrom 0.3 A
Kontaktwiderstand 200 mΩ
Logistics
Ursprungsland CN
Zolltarifnummer 85365080
MSL MSL 1
Compliance
RoHS konform Yes
Stand der RoHS-Richtlinie 3/31/15
SVHC frei Yes
