7-1393211-2 | Potter & Brumfield
Relay, 2 Form A (N/O), 48 V (DC), 1390 Ω, 30 A, 600 V (AC), monostable, 7-1393211-2
Unit Price (€ / pc.)
20.3014 € *
Available: 0 pcs.
Available in 5 Days: 24 pcs.
Leadtime: 26 Weeks **
Total Price:
20.30 € *
Price list
Quantity
Price per unit*
5 pcs.
20.3014 €
22 pcs.
19.1233 €
*incl. VAT plus shipping costs
**Subject to prior sale
Power relay, 7-1393211-2, Potter & Brumfield
Power relay, Standard, Monostable, DC, 1700 mW Coil Power Rating DC, 1390 Ω Coil Resistance, UL Coil Insulation Class F
Features
- Designed to control compressor loads
- Printed circuit board mount
- Dust protected plastic case
- Meets requirements of UL Class F construction
Applications
- Residential / commercial appliances
- Industrial Control
- Charging
- HVAC
Technical specifications
| Anschluss | Flachstecker | |
| Kontaktart | 2 Schließer | |
| Kontaktmaterial | AgCdO | |
| Schaltspannung (AC) | 600 V | |
| Schaltstrom | 30 A | |
| Spulenspannung (DC) | 48 V | |
| Spulentyp | monostabil | |
| Spulenwiderstand | 1390 Ω |
Download
Logistics
| Ursprungsland | CN |
| Zolltarifnummer | 85364110 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | No |
| Substanz Beschreibung | Cadmiumoxid |
