1.10.011.001/0221 | RAFI
Pushbutton, illuminable, groping, 1 Form A (N/O), waistband round, white, front ring black, mounting Ø 22.3 mm, 1.10.011.001/0221
Unit Price (€ / pc.)
65.5214 € *
Available: 8 pcs.
Leadtime: 4 Weeks **
Total Price:
65.52 € *
Price list
Quantity
Price per unit*
1 pcs.
65.5214 €
10 pcs.
57.6674 €
20 pcs.
56.0847 €
40 pcs.
54.5139 €
160 pcs.
51.3723 €
*incl. VAT plus shipping costs
**Subject to prior sale
Pushbutton, 1.10.011.001/0221, RAFI
By using the RAFI MICON 5 short-stroke pushbutton, RAMO 22 T offers tactile feedback with a clear key click. Thanks to its IP 66/IP69K degree of protection, it is particularly recommended for plant construction. RAMO 22 T require an installation diameter of 22.3 mm. Contact function: 1 NO contact, actuating function: momentary, colour of bezel: white, colour of front rings: black, shape of collar: round, connection type: M12.
Technical specifications
| Connection | M12 plug, 4 pole | |
| Version | pushbutton | |
| Type of mounting | threaded ring | |
| can be illuminated | Yes | |
| Collar shape of the front frame | round | |
| Installation diameter | 22.3 mm | |
| Installation height | 10 mm | |
| Installation depth | 30.2 mm | |
| Actuator colour | white | |
| Front ring colour | black | |
| Contact function | groping | |
| Contact material | gold | |
| Latching switching function | 1 Form A (N/O) | |
| Protection class | IP66/IP67/IP69K |
Download
Logistics
| Country of origin | HU |
| Customs tariff number | 85365011 |
| Original Packaging | Carton with 10 pieces |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
