1.30.276.001/2200 | RAFI

Mushroom pushbutton, illuminable, latching, waistband round, white/black, mounting Ø 22.3 mm, 1.30.276.001/2200

Order No.: 12G3544
EAN: 4099889246384
MPN:
1.30.276.001/2200
Series: RAFIX 22 FS+
1.30.276.001/2200 RAFI Actuators, Signal Elements and Front Elements
Image may differ
Unit Price (€ / pc.)
19.1709 € *
Available: 0 pcs.
Leadtime: 9 Weeks **
Total Price:
19.17 € *
*incl. VAT plus shipping costs
**Subject to prior sale
1 pcs.
19.1709 €

Mushroom pushbutton, 1.30.276.001/2200, RAFI

The mushroom pushbuttons are protected against unintentional actuation by a positively driven mechanical movement sequence according to DIN EN ISO 13850. To protect against unintentional actuation, a pressure point must be overcome and the pushbutton engages in the pressed position. Exception: The versions 1.30.276.201/xxxx and 1.30.276.701/xxxx are momentary.

Features

  • Black mushroom button with central illuminated transparent window
  • Low installation depth 9.2 mm (PCB) or 27 mm (QC)
  • Connection types: printed circuit board connection (PCB) or plug-in connection (QC)
  • The PCB switching elements minimize assembly errors
  • Switching elements with silver contacts (max. 250 V/4 A) or gold contacts (max. 35 V/100 mA)
  • Degree of protection: IP 65 front side
Technical specifications
Ausführung Pilztaster
Befestigungsart Gewindering
Beleuchtbar Yes
Bundform rund
Einbaudurchmesser 22.3 mm
Einbauhöhe 33.2 mm
Einbautiefe 9.2 mm
Farbe Betätiger weiß/schwarz
Kontaktfunktion rastend
Schutzart (Betätigungsseite) IP65
Logistics
Ursprungsland HU
Zolltarifnummer 85365080
Compliance
RoHS konform Yes
Stand der RoHS-Richtlinie 3/31/15
SVHC frei Yes
