109858-000 | Raychem
Butt connector kit with heat shrink insulation, 0.38 mm², AWG 22, transparent blue, 17 mm, 109858-000
Order No.: 34P3396
EAN: 4099889605174
MPN:
109858-000
D-181-1222-90/9
Unit Price (€ / pc.)
8.6275 € *
Available: 0 pcs.
Leadtime: On Request **
Total Price:
8.63 € *
Price list
Quantity
Price per unit*
1 pcs.
8.6275 €
10 pcs.
7.9373 €
50 pcs.
7.1400 €
100 pcs.
6.4260 €
*incl. VAT plus shipping costs
**Subject to prior sale
Coax Cable Termination, 109858 - 000, Raychem
Temperature Indicator: No, Coax Cable Termination Product Type: Coax Terminator, Coax Cable Termination Applies To: Coaxial Cable, Splice Type: SolderSleeve, Pre - Installed Lead Type: 55A0111, Lead Stranding: Stranded, Cable Shield Material: Silver,Tin, Shield Outside Diameter (Max): 3.2 mm, Termination Method: Solder, Pre - Installed Lead Wire Size: 0.38 mm², Jacket Outside Diameter: 1.5 - 3.6 mm, Coax Cable Termination Conductor Outside Diameter: 0.25 - 0.7 mm, Dielectric Outside Diameter: 2.4 mm, Overall Length: 17 mm,21.5 mm, Resistance Properties: Immersion Protection, Coax Cable Termination Operating Temperature (Max): 150 °C, MIL/NAS Specification (MIL - S - 83519, NAS - 1747): No, Government Qualified: No
Technical specifications
| Ausführung | Stoßverbinder Set | |
| AWG-Leiterquerschnitt | AWG 22 | |
| Farbe | transparent blau | |
| Isoliert | Yes | |
| Länge | 17 mm | |
| Leiterquerschnitt | 0,38 mm² | |
| Material | PVDF | |
| Schrumpfschlauch | Yes |
Download
Logistics
| Ursprungsland | US |
| Zolltarifnummer | 85369095 |
Compliance
| RoHS konform | No |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | No |
| Substanz Beschreibung | Blei |
