9264634014 | Raychem
Heatshrink tubing, 3:1, (12/4 mm), PE, clear, 9264634014
Unit Price (€ / mtr.)
6.6997 € *
Available: 0 mtr.
Available in 5 Days: 200 mtr.
Leadtime: 56 Weeks **
Heat shrink tubing, 9264634014, Raychem
The 9264634014 is a heat-shrinkable tub that environmentally seals and protects components and interconnections. High expansion ratio makes it possible to repair most damaged cable jackets without removing connectors.
Features
- Medium wall provides increased mechanical protection
- RoHS compliant
Technical specifications
| Colour | clear | |
| Inner diameter after shrinkage | 4 mm | |
| Inner diameter before shrinkage | 12 mm | |
| Material | PE | |
| max. operating temperature | 110 °C | |
| min. operating temperature | -55 °C | |
| Shrinking rate | 3:1 | |
| Shrinking temperature | 80 °C | |
| Wall thickness | 1.78 mm |
Download
Logistics
| Country of origin | CZ |
| Customs tariff number | 39269097 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | 6,6'-di-tert-butyl-2,2'-methylenedi-p-cresol |
