616 667 3 1 | Rennsteig Werkzeuge
Crimping pliers for D-Sub, 0.03-2.5 mm², AWG 32-14, Rennsteig Werkzeuge 616 667 3 1
Unit Price (€ / pc.)
477.8683 € *
Available: 0 pcs.
Leadtime: 2 Weeks **
Crimping Plier, 616 667 3 1, RENNSTEIG
Pliers with real system character due to easily exchangeable crimping dies and contact holders, parallel crimping jaw guidance, preferably for constructively small connectors in the crimping range 0.03-2.5 mm², AWG 32-14, small and compact design, holder for exact positioning of the contacts, with ratchet (unlockable) for reliable crimping, low manual force required due to optimum transmission ratio, ergonomic and non-slip 2k handles, with crimping dies and contact receptacle for D-Sub, HD 20, HDE connectors 0.03-0.09mm², 0.08-0.2mm² and 0.2-0.56mm², F-Crimp, Made in Germany
Technical specifications
| Crimping Range (AWG) | AWG 32-14 | |
| Crimping Range (mm²) | 0.03-2.5 mm² | |
| Suitable for | D-Sub | |
| Weight | 305 g | |
| Length | 190 mm |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 82032000 |
Compliance
| RoHS conform | not_relevant |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Lead |
