102883 | Riegler
2/2-way solenoid valve, NC, 0-18 bar, 230 V, 102883
Order No.: 63G438
EAN: 4047322158664
MPN:
102883
MV 1311
Unit Price (€ / pc.)
39.6270 € *
Available: 0 pcs.
Available in 3 Days: 9 pcs.
Leadtime: On Request **
Total Price:
39.63 € *
Price list
Quantity
Price per unit*
1 pcs.
39.6270 €
5 pcs.
37.7944 €
10 pcs.
36.1284 €
*incl. VAT plus shipping costs
**Subject to prior sale
Solenoid valve, 102883, Riegler
The 102883 is a directly operated piston valve with a compact design, easy installation and short response time. The media valve for shutting off gaseous or liquid media that are compatible with the materials used, the high-quality materials used for the valves and extensive testing guarantee a long service life.
Features
- The valves do not require a minimum operating pressure
- Any mounting position
Technical specifications
| Anschluss | Gerätesteckdose PG 9/PG 11 | |
| Ausführung | 2/2-Wege-Magnetventil, NC | |
| Druckbereich | 0-18 bar | |
| Nennspannung | 230 V | |
| Nennweite | 2.3 mm |
Download
Logistics
| Ursprungsland | IT |
| Zolltarifnummer | 84812090 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
