RE521-LF | Roth Elektronik
Lab board, 100 x 160 mm, pitch 2.54 mm, single sided, FR4 epoxy, Cu 35 µm, RE521-LF
Order No.: 10H8204
EAN: 4099889462838
MPN:
RE521-LF
Abgekündigt
Unit Price (€ / pc.)
8.8655 € *
Available: 17 pcs.
Leadtime: 3 Weeks **
Total Price:
8.87 € *
Price list
Quantity
Price per unit*
1 pcs.
8.8655 €
10 pcs.
7.7945 €
50 pcs.
7.2709 €
150 pcs.
6.9496 €
500 pcs.
6.5926 €
*incl. VAT plus shipping costs
**Subject to prior sale
Prototyping board, RE521-LF, Roth Elektronik
Single-sided with 35 µm copper plating. Option for installing connectors to DIN 41612 design C (32-pole; grid: 5.08 mm). Format: 100 x 160 mm. Substrate: phenolic resin laminated paper FR 2, organic surface protection (OSP) or epoxy resin FR 4, hot-tinned (HAL lead-free). Grid: 2.54 x 2.54 mm. Hole matrix: 37 PCB traces, each with 57 holes. Hole diameter: 1.0 mm. Board thickness: 1.5 mm, component side with assembly labeling.
Technical attributes (type, format, substrate): RE521-LF, 100 x 160 mm, epoxy resin.
Technical specifications
| Ausführung | Laborkarte | |
| Breite | 160 mm | |
| Durchkontaktiert | No | |
| Ein-/Zweiseitig | einseitig | |
| Höhe | 1.5 mm | |
| Kupferstärke | 35 m | |
| Länge | 100 mm | |
| Lochdurchmesser | 1 mm | |
| Material | FR4 Epoxid | |
| Oberflächenart | Heißluft-Verzinnung (HAL) | |
| Rastermaß | 2.54 mm |
Download
Logistics
| Ursprungsland | BG |
| Zolltarifnummer | 85340019 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
