10TKV220M6.3X8 | Rubycon
Electrolytic capacitor, 220 µF, 10 V (DC), ±20 %, SMD, Ø 6 mm, 10TKV220M6.3X8
Unit Price (€ / pc.)
0.2463 € *
Available: 0 pcs.
Leadtime: On Request **
Total Price:
3,325.46 € *
*incl. VAT plus shipping costs
**Subject to prior sale
13500 pcs.
0.2463 €
Electrolytic capacitor, 10TKV220M6.3X8, RUBYCON
Aluminum electrolytic capacitor - SMD
Features
- Low ESR
- Load Life: 105℃ 2000 hours
- RoHS-compatible
Applications
- Automotive electronics
- Audio signal circuits
- Optical equipment
- Measuring equipment
Technical specifications
| Ausführung | Polar | |
| Bauform | SMD | |
| Durchmesser | 6 mm | |
| ESR (Äquivalenter Serienwiderstand) | 160 mΩ | |
| Kapazität | 220 µF | |
| Länge | 8 mm | |
| max. Temperatur | 105 °C | |
| min. Temperatur | -55 °C | |
| Nennspannung (DC) | 10 V | |
| Rippelstrom | 600 mA | |
| Toleranz | ±20 % |
Download
Logistics
| Ursprungsland | JP |
| Zolltarifnummer | 85322200 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
