FN351-50-47 | Schaffner
EMC filter, 60 Hz, 50 A, 3x 440/250 VAC, 22 kW, terminal block, FN351-50-47
Unit Price (€ / pc.)
284.1958 € *
Available: 0 pcs.
Leadtime: On Request **
3-Phase filter, FN351-50-47, SCHAFFNER
General purpose EMC filter
Features
- EMC solution for industrial inverters and motor drive
- High differential and common-mode attenuation
- Solid, touch-safe filter terminals contribute to overall equipment safety
Applications
- Three-phase motor drive
- Inverters and converters
- Industrial automation equipment
- UPS
- SMPS
Technical specifications
| Anschluss | Klemmleiste | |
| Anzahl der Phasen | 3 | |
| Ausführung | EMC Filter | |
| Bemessungsspannung | 3x 440/250 VAC | |
| Leistung | 22 kW | |
| max. Frequenz | 60 Hz | |
| max. Temperatur | 85 °C | |
| min. Temperatur | -25 °C | |
| Mit Sicherung | No | |
| Nennstrom | 50 A |
Download
Logistics
| Ursprungsland | TH |
| Zolltarifnummer | 85363010 |
| Originalverpackung | Karton mit 5 Stück |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
