9422ATCF331 | Schneider Electric
Operating mechanism, flange mounted, variable depth, 30A, 600 V, fuseholder, switch mechanism, 6 inch handle, NEMA 4
Order No.: 01P6696
EAN: 4099889275339
MPN:
9422ATCF331
Unit Price (€ / pc.)
670.0414 € *
Available: 0 pcs.
Leadtime: On Request **
Switch disconnector, 9422ATCF331, Schneider Electric
Type S non-reversing magnetic starters are for motor control applications. NEMA Size 0 starters have ratings of 1 HP at 115 and 2 HP at 230 single phase and has a maximum rating of 18 Amps. This 2 pole starter is for single phase applications. These starters are available with a wide variety of replaceable coil voltages. Starter has a 110/120 VAC 50/60 Hz operating coil wired for separate control. The melting alloy type overload relay uses Type B thermal units to sense over current conditions. This contactor doesn't have an enclosure. Starter is 6.77 inches tall, 3.50 inches wide and 4.22 inches deep. A wide variety of accessories are available for Type S starters. Type S starters are UL listed and CSA certified for global applications.
Technical specifications
| Permanent current | 30 A | |
| Pin number | 3 pole |
Download
Logistics
| Country of origin | MX |
| Customs tariff number | 85365080 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Lead |
| Sustainable | Yes |
