A9N61651 | Schneider Electric
Circuit breaker, 2 pole, B Curve, 16 A, 800 V, DIN rail, A9N61651
Unit Price (€ / pc.)
108.8017 € *
Available: 0 pcs.
Leadtime: On Request **
Circuit breaker, A9N61651, SCHNEIDER
The A9N61651 is a low voltage miniature circuit breaker dedicated to multi string photovoltaic installations. It is a 2P circuit breaker with 2 protected poles and 16 A In rated current and B tripping curve. The rated short circuit breaking capacity goes up to 1.5 kA at 800 V DC. This miniature circuit breaker protects circuits against short circuit and overload current.
Features
- High breaking capacity
- High rated impulse withstand voltage
- High mechanical durability
- High electrical durability
Technical specifications
| Auslösecharakteristik | B | |
| Bemessungsspannung | 800 V | |
| Bemessungsstrom | 16 A | |
| Montage | DIN-Schiene | |
| Nennspannung (DC) | 800 V | |
| Polzahl | 2-polig |
Download
Logistics
| Ursprungsland | CN |
| Zolltarifnummer | 85362010 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
| Nachhaltig | Yes |
