LA1KN31M | Schneider Electric
Auxiliary switch block, 4 pole, 10 A, 690 V, 3 Form A (N/O) + 1 Form B (N/C), screw connection, LA1KN31M
Unit Price (€ / pc.)
14.1134 € *
Available: 0 pcs.
Leadtime: On Request **
Auxiliary switch block, LA1KN31M, Schneider Electric
TeSys K instantaneous auxiliary contact block, for contactors LC.K, LP.K (3P + 1NO contact models except LP4K, LP5K) with screw clamp terminals. It provides 3NO+1NC contacts rated up to 10A 690V AC, connection by screw clamp terminals. Marking on terminals conforms to EN 50012. Front mounting by clip-on, it procures high reliability and durability. Multi standards certified (IEC, UL, CSA, CCC), Green Premium compliant (RoHS/REACh).
Technical specifications
| Connection | screw connection | |
| Version | auxiliary switch block | |
| Rated Voltage | 690 V | |
| Assembly | front mounting | |
| Rated current | 10 A | |
| Pin number | 4 pole | |
| Latching switching function | 3 Form A (N/O) + 1 Form B (N/C) | |
| Degree of protection (IP) | IP20 |
Download
Logistics
| Country of origin | FR |
| Customs tariff number | 85365080 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| Sustainable | Yes |
