LC1K12004B7 | Schneider Electric
Power contactor, 4 pole, 20 A, 4 Form A (N/O), coil 24 VAC, screw connection, LC1K12004B7
Unit Price (€ / pc.)
39.4961 € *
Available: 0 pcs.
Leadtime: 1 Week **
Power contactor, LC1K12004B7, Schneider Electric
TeSys K contactor, 4 poles (4NO), for non-inductive load control applications up to 20A/690V AC-1. It provides a 24V 50/60Hz AC coil, without built-in auxiliary contact, connection by screw clamp terminals. For operating rates until 600 cycles/hour and environments until 50°C, it procures reliability and durability to standard applications. Very compact (45mm width), DIN-rail mounting or screw fixing. Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh).
Technical specifications
| Connection | Schraubanschluss | |
| Version | Leistungsschütz | |
| rated voltage (AC) | 440 V | |
| Assembly | DIN-Schiene/Schraube | |
| Rated current | 20 A | |
| Pin number | 4-polig | |
| Latching switching function | 4 Schließer | |
| Control Voltage | 24 VAC |
Download
Logistics
| Country of origin | FR |
| Customs tariff number | 85364900 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
| Sustainable | Yes |
