LC2K1201P7 | Schneider Electric
Reversing contactor, 3 pole, 12 A, 400 V, 3 Form A (N/O), coil 230 VAC, screw connection, LC2K1201P7
Unit Price (€ / pc.)
98.1512 € *
Available: 0 pcs.
Leadtime: On Request **
Reversing contactor combination, LC2K1201P7, Schneider Electric
TeSys K reversing contactor, 3 poles (3NO), for motor control applications up to 12A/690V AC-3 (5.5kW@400V). It provides 230V 50/60Hz AC coils, 2NC built-in auxiliary contacts, connection by screw clamp terminals. For operating rates until 600 cycles/hour in AC-3 and environments until 50°C, it procures reliability and durability to standard applications. Compact (90mm width), DIN-rail mounting or screw fixing. With pre-wired reversing power connections, mechanical interlock (without electrical interlocking). Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh).
Technical specifications
| Anschluss | Schraubanschluss | |
| Ausführung | Wendeschütz | |
| Bemessungsspannung (AC) | 440 V | |
| Bemessungsspannung | 400 V | |
| Montage | DIN-Schiene/Schraube | |
| Nennstrom | 12 A | |
| Polzahl | 3-polig | |
| Schaltfunktion | 3 Schließer | |
| Schutzart (IP) | IP20 | |
| Steuerspannung | 230 VAC |
Download
Logistics
| Ursprungsland | FR |
| Zolltarifnummer | 85364900 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
| Nachhaltig | Yes |
