M9A26947 | Schneider Electric

Shunt release + auxiliary switch, MX+OF 48 V AC/DC, for Multi9 C60BP/C60BPR/C60SP/GFP/C60H-DC, M9A26947

Order No.: 03P7736
EAN: 4099889174106
MPN:
M9A26947
Series: C60 UL/CSA/IEC
M9A26947 Schneider Electric Fuses Accessories
Image may differ
Unit Price (€ / pc.)
59.8689 € *
Available: 0 pcs.
Leadtime: On Request **
Total Price:
59.87 € *
*incl. VAT plus shipping costs
**Subject to prior sale
1 pcs.
59.8689 €

Shunt trip release with OC contact, M9A26947, Schneider Electric

This Multi9 MX+OF electrical auxiliary is a shunt trip release with OC contact. It is dedicated to Multi9 GFP, C60BP, C60SP, C60BPR. The width in 9 mm pitches is 2. The Uc control circuit voltage is 48 VAC or 48 VDC. It can be mounted on a DIN rail for modular installation. The operating temperature is -25°C to 50°C. The storage temperature is -40°C to 85°C. This product complies with EN/IEC 60947-1 standard.

Technical specifications
Version MX+OF 48 V AC/DC
Suitable for Multi9 C60BP/C60BPR/C60SP/GFP/C60H-DC
Accessory Type shunt release + auxiliary switch
Logistics
Country of origin BE
Customs tariff number 85365080
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
Sustainable Yes
