NSYPLAZT10103G | Schneider Electric

Control cabinet, (H x W x D) 1000 x 1000 x 320 mm, IP44, polyester, light gray, NSYPLAZT10103G

Order No.: 02P1869
EAN: 3606480775956
MPN:
NSYPLAZT10103G
Series: Thalassa PLA
Schneider Electric
NSYPLAZT10103G Schneider Electric Switch Cabinets, server cabinets
Image may differ
Unit Price (€ / pc.)
1,274.0973 € *
Available: 0 pcs.
Leadtime: On Request **
Total Price:
1,274.10 € *
*incl. VAT plus shipping costs
**Subject to prior sale
1 pcs.
1,274.0973 €

Floor standing polyester enclosure, NSYPLAZT10103G, Schneider Electric

This PLAZT version of the PLA is a versatile, floor-standing enclosure that is suitable for various applications. It measures 1000 mm in height, 1000 mm in width, and 320 mm in depth, also is made of polyester reinforced with fiberglass for durability and resistance to harsh environments, both indoor and outdoor. The enclosure is available in grey (RAL 7035) and consists of two side parts, two plain front doors, two rear panels, one canopy, and one plinth. The doors open up to 180° from either the right or left side, providing easy access to the equipment inside The doors are fitted with a four-point lock and a handle with a 5 mm double-bar insert.

The doors, rear panels, and canopy can be removed for maintenance purposes. The enclosure offers robust protection against various hazards, including fire, impact, dust, and water. It can withstand fire up to 960 °C in accordance with the IEC 62208 standard. The enclosure also has an IP44 rating (IEC 60529), offering high protection against dust and water additionally. The enclosure has class II electrical insulation to prevent electric shocks and allow for the building of totally insulated solutions.

Technical specifications
Version control cabinet
Width 1000 mm
Colour light gray
Height 1000 mm
Material polyester
Degree of protection (IP) IP44
Depth 320 mm
Logistics
Country of origin ES
Customs tariff number 85381000
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
Sustainable Yes
