VZ1L018UM20 | Schneider Electric
Line choke, 1-phase, for Frequency converter, VZ1L018UM20
Unit Price (€ / pc.)
195.7193 € *
Available: 0 pcs.
Leadtime: 1 Week **
Line choke, VZ1L018UM20, Schneider Electric
This line choke can be used to provide improved protection against overvoltages on the line supply. It can also be used to reduce harmonic distortion of the current produced by the drive. This product is compliant with IEC 61800-5-1 (VDE 0160 level 1 high-energy overvoltages on the line supply). Its rated current is equal to 18A and its value of inductance to 2mH. It is compatible with Altivar 31, Altivar 32, Altivar 312, Altivar machine ATV320, Lexium 05 and Lexium 32.
Technical specifications
| Number of phases | 1 | |
| Version | line choke | |
| Width | 85 mm | |
| Suitable for | Frequency converter | |
| Height | 120 mm | |
| Depth | 105 mm |
Download
Logistics
| Country of origin | FR |
| Customs tariff number | 85045000 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
