3-2158100-4 | Schrack
Relay, 1 Form C (NO/NC), 12 V (DC), 272 Ω, 16 A, 400 V (AC), monostable, 3-2158100-4
Unit Price (€ / pc.)
1.6898 € *
Available: 0 pcs.
Available in 5 Days: 4,532 pcs.
Leadtime: 52 Weeks **
Total Price:
1.69 € *
Price list
Quantity
Price per unit*
60 pcs.
1.6898 €
260 pcs.
1.6541 €
*incl. VAT plus shipping costs
**Subject to prior sale
Power relay, 3-2158100-4, Schrack
Power relay, Standard, Monostable, DC, 530 mW Coil Power Rating DC, 272 Ω Coil Resistance, UL Coil Insulation Class F.
Applications
- Household appliances
- Boiler control
- Garage door control
- Timers
Technical specifications
| Connection | PCB pin | |
| Contact type | 1 Form C (NO/NC) | |
| Contact material | AgNi 90/10 | |
| Switching Voltage (AC) | 400 V | |
| switching current | 16 A | |
| Coil voltage (DC) | 12 V | |
| Coil type | monostable | |
| Coil resistance | 272 Ω |
Download
Logistics
| Country of origin | AT |
| Customs tariff number | 85364900 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
