7-1415517-1 | Schrack
Relay, 1 Form A (N/O), 12 V (DC), 360 Ω, 16 A, 400 V (AC), monostable, 7-1415517-1
Unit Price (€ / pc.)
9.9008 € *
Available: 0 pcs.
Available in 5 Days: 110 pcs.
Leadtime: 21 Weeks **
Total Price:
9.90 € *
Price list
Quantity
Price per unit*
10 pcs.
9.9008 €
55 pcs.
8.3181 €
*incl. VAT plus shipping costs
**Subject to prior sale
Power relay, 7-1415517-1, Schrack
Power relay, Standard, Monostable, DC, 400 mW Coil Power Rating DC, 360 Ω Coil Resistance, UL Coil Insulation Class F.
Features
- Reinforced insulation
- Quick connect terminals for load side
Applications
- Oven control
- Electric heating
- Power supplies
- Air conditioning
- Microwave ovens
Technical specifications
| Connection | Plug-in/PCB connection | |
| Contact type | 1 Form A (N/O) | |
| Contact material | AgNi 90/10 | |
| Switching Voltage (AC) | 400 V | |
| switching current | 16 A | |
| Coil voltage (DC) | 12 V | |
| Coil type | monostable | |
| Coil resistance | 360 Ω |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85364900 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
