69001-728 | SCHROFF

Name: Connector Type R, EN 60603, DIN 41612, Female,96 Contacts, Solder Pins, 3 mm
Brand: SCHROFF
SKU: 85H6678
Price: 9.71 EUR
Availability: OutOfStock

Connector Type R, EN 60603, DIN 41612, Female,96 Contacts, Solder Pins, 3 mm

Order No.: 85H6678

EAN: 4036088067778

MPN:

69001-728

Image may differ

Key Specification:

Ausführung Federleiste

Kontaktart Buchse

Polzahl 96-polig

Rastermaß 2.54 mm

Anschluss Lötstift

Show 39 variants

Download Datasheet Technical specifications

Unit Price (€ / pc.)

9.7104 € *

Available: 0 pcs.

Leadtime: On Request **

Add to Cart

Total Price:

9.71 € *

*incl. VAT plus shipping costs

**Subject to prior sale

Description

Male / Female DIN connector form R. Requirement class 2 as per EN 60603 (DIN 41642).

Download

Technisches Datenblatt - EN Technisches Datenblatt

Konformitätsdeklaration - EN Konformitätsdeklaration

Technisches Datenblatt - DE Technisches Datenblatt

Konformitätsdeklaration - DE Konformitätsdeklaration

Logistics

Ursprungsland	CZ
Zolltarifnummer	85369010

Compliance

RoHS konform	Yes
Stand der RoHS-Richtlinie	3/31/15
SVHC frei	Yes

1 item in 39 variations
