69001-831 | SCHROFF

Name: Connector Type D, EN 60603, DIN 41612, Male,32 Contacts, Solder Pins, 3 mm
Brand: SCHROFF
SKU: 85H6685
Price: 4.34 EUR
Availability: OutOfStock

Connector Type D, EN 60603, DIN 41612, Male,32 Contacts, Solder Pins, 3 mm

Order No.: 85H6685

EAN: 4036088067846

MPN:

69001-831

Image may differ

Key Specification:

Version Messerleiste

Contact type Stift

Pin number 32-polig

Grid 5.08 mm

Connection Lötstift

Show 39 variants

Download Datasheet Technical specifications

Unit Price (€ / pc.)

4.3435 € *

Available: 0 pcs.

Leadtime: 9 Weeks **

Total Price:

43.43 € *

*incl. VAT plus shipping costs

**Subject to prior sale

Description

Male / Female DIN connector form D. Requirement class 2 as per EN 60603 (DIN 41642).

Download

Technisches Datenblatt - EN Technisches Datenblatt

Konformitätsdeklaration - EN Konformitätsdeklaration

Technisches Datenblatt - DE Technisches Datenblatt

Konformitätsdeklaration - DE Konformitätsdeklaration

Logistics

Country of origin	CH
Customs tariff number	85369010

Compliance

RoHS conform	Yes
Date of RoHS guidelines	3/31/15
SVHC free	Yes

Accessory
