69001-877 | SCHROFF

Name: Connector Type E, EN 60603, DIN 41612, Female,48 Contacts, Wire-Wrap, 22 mm
Brand: SCHROFF
SKU: 85H6693
Price: 15.45 EUR
Availability: OutOfStock

Connector Type E, EN 60603, DIN 41612, Female,48 Contacts, Wire-Wrap, 22 mm

Order No.: 85H6693

EAN: 4036088067921

MPN:

69001-877

Image may differ

Key Specification:

Version Federleiste

Contact type Buchse

Pin number 48-polig

Grid 5.08 mm

Connection Wire-wrap

Show 39 variants

Download Datasheet Technical specifications

Unit Price (€ / pc.)

15.4462 € *

Available: 0 pcs.

Leadtime: On Request **

Total Price:

77.23 € *

*incl. VAT plus shipping costs

**Subject to prior sale

Description

Male / Female DIN connector form E. Requirement class 2 as per EN 60603 (DIN 41642).

Download

Technisches Datenblatt - EN Technisches Datenblatt

Konformitätsdeklaration - EN Konformitätsdeklaration

Technisches Datenblatt - DE Technisches Datenblatt

Konformitätsdeklaration - DE Konformitätsdeklaration

Logistics

Country of origin	DE
Customs tariff number	85369010

Compliance

RoHS conform	Yes
Date of RoHS guidelines	3/31/15
SVHC free	Yes

1 item in 39 variations

*incl. VAT plus shipping costs
