ITNF-0239-D202 | SCHURTER
Schurter ITNF-0239-D202
Unit Price (€ / pc.)
4.7005 € *
Available: 0 pcs.
Leadtime: 40 Weeks **
Total Price:
4.70 € *
Price list
Quantity
Price per unit*
1 pcs.
4.7005 €
10 pcs.
4.2364 €
50 pcs.
3.8080 €
100 pcs.
3.4272 €
*incl. VAT plus shipping costs
**Subject to prior sale
Pulse transformer, ITNF-0239-D202, SCHURTER
Pulse transformer for THT mounting.
Features
- High insulation rating (>3.2 kVAC) between the primary and the secondary windings
- High insulation rating up to 500 V between the secondary windings
- Small coupling capacitances between primary and secondary windings limit transient feedback from the power supply side to the control electronics
- The defined partial discharge voltage guarantees an effecively unlimited serviceable live
Application
- Galvanic separation of drive- and power-circuit
- Mainly used in ignition circuits with Thyristors, Triacs, power transistors and IGBT's
- DC/DC Converters
- Line coupling transformers in high speed data transmission
Technical specifications
| Bauform | THT | |
| Breite | 22.7 mm | |
| Gleichstromwiderstand | 0.4 Ω | |
| Höhe | 13.6 mm | |
| Induktivität | 1.6 mH | |
| Länge | 22.3 mm | |
| max. Temperatur | 100 °C | |
| min. Temperatur | -25 °C | |
| Windungsverhältnis | 1:1:1 |
Download
Logistics
| Ursprungsland | LK |
| Zolltarifnummer | 85043180 |
| MSL | MSL 1 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
