DFSG-30-0002 | SCHURTER
Saturating choke, radial, 6 A, DFSG-30-0002
Unit Price (€ / pc.)
4.4506 € *
Available: 0 pcs.
Leadtime: 21 Weeks **
Saturating choke, DFSG-30-0002, SCHURTER
The DFSG-30-0002 changes impedance at the moment of switching, and can be used to attenuate differential-mode noise or symmetrical interference as generated in fast switching high current applications.
Features
- Saturating choke
- THT-terminals
- Fully potted resign
- Based on laminated iron core
Applications
- Phase angle control circuits with thyristors, triacs or transistors
- The choke acts at its optimum when it is mounted directly at the interference originator (thyristor, triac)
Technical specifications
| Ausführung | Sättigungsdrossel | |
| Bauform | radial | |
| Breite | 30 mm | |
| Gleichstrom | 6 A | |
| Gleichstromwiderstand | 60 mΩ | |
| Höhe | 22 mm | |
| Länge | 30 mm |
Download
Logistics
| Ursprungsland | LK |
| Zolltarifnummer | 85045000 |
| MSL | MSL 1 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
