DKFS-B22B-D439 | SCHURTER
Suppressor choke, SMD, 39 mH, 0.4 A, DKFS-B22B-D439
Unit Price (€ / pc.)
4.7005 € *
Available: 0 pcs.
Leadtime: 41 Weeks **
Total Price:
4.70 € *
Price list
Quantity
Price per unit*
1 pcs.
4.7005 €
10 pcs.
4.2245 €
50 pcs.
3.8080 €
100 pcs.
3.4272 €
*incl. VAT plus shipping costs
**Subject to prior sale
Suppressor inductor, DKFS-B22B-D439, SCHURTER
The DKFS-B22B-D439 is a current compensated choke. It is used for limiting currents in electrical lines, for intermediate storage of energy, for impedance matching or for filtering.
Features
- Current compensated choke
- SMD-terminals
- Vertical and horizontal version
Applications
- Attenuation of common mode interferences
- Designed for 230/400 VAC applications
- DC drives and stepper motor controls
- Switching power supplies
Technical specifications
| Version | suppressor choke | |
| Design | SMD | |
| Width | 10.7 mm | |
| DC current | 0.4 A | |
| DC resistance | 1286 mΩ | |
| Height | 11 mm | |
| Inductance | 39 mH | |
| Length | 13.5 mm | |
| Tolerance | -30/+50 % |
Download
Logistics
| Country of origin | LK |
| Customs tariff number | 85045000 |
| MSL | MSL 1 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
