DKFS-B22B-D527 | SCHURTER
Suppressor choke, SMD, 27 mH, 0.5 A, DKFS-B22B-D527
Unit Price (€ / pc.)
4.7005 € *
Available: 0 pcs.
Leadtime: 40 Weeks **
Total Price:
4.70 € *
Price list
Quantity
Price per unit*
1 pcs.
4.7005 €
10 pcs.
4.2245 €
50 pcs.
3.8080 €
100 pcs.
3.4272 €
*incl. VAT plus shipping costs
**Subject to prior sale
Suppressor inductor, DKFS-B22B-D527, SCHURTER
The DKFS-B22B-D527 is a current compensated choke. It is used for limiting currents in electrical lines, for intermediate storage of energy, for impedance matching or for filtering.
Features
- Current compensated choke
- SMD-terminals
- Vertical and horizontal version
Applications
- Attenuation of common mode interferences
- Designed for 230/400 VAC applications
- DC drives and stepper motor controls
- Switching power supplies
Technical specifications
| Ausführung | Entstördrossel | |
| Bauform | SMD | |
| Breite | 10.7 mm | |
| Gleichstrom | 0.5 A | |
| Gleichstromwiderstand | 841 mΩ | |
| Höhe | 11 mm | |
| Induktivität | 27 mH | |
| Länge | 13.5 mm | |
| Toleranz | -30/+50 % |
Download
Logistics
| Ursprungsland | LK |
| Zolltarifnummer | 85045000 |
| MSL | MSL 1 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
