Suppressor choke, radial, 6.9 mH, 10 A, DKIH-3237-1010-NK
Unit Price (€ / pc.)
22.4553 € *
Available: 0 pcs.
Leadtime: 9 Weeks **
Total Price:
22.46 € *
Price list
Quantity
Price per unit*
1 pcs.
22.4553 €
10 pcs.
20.6584 €
25 pcs.
19.0043 €
50 pcs.
17.2907 €
*incl. VAT plus shipping costs
**Subject to prior sale
Suppressor inductor, DKIH-3237-1010-NK, SCHURTER
The DKIH-3237-1010-NK is a current compensated choke. It is used for limiting currents in electrical lines, for intermediate storage of energy, for impedance matching or for filtering.
Features
- Current compensated choke
- SMD-terminals
- Vertical and horizontal version
Applications
- Attenuation of common mode interferences
- Designed for 230/400 VAC applications
- DC drives and stepper motor controls
- Switching power supplies
Technical specifications
| Ausführung | Entstördrossel | |
| Bauform | radial | |
| Gleichstrom | 10 A | |
| Gleichstromwiderstand | 10 mΩ | |
| Höhe | 26 mm | |
| Induktivität | 6.9 mH | |
| Toleranz | -30/+50 % |
Download
Logistics
| Ursprungsland | CN |
| Zolltarifnummer | 85045000 |
| MSL | MSL 1 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
