DLFP-0125-08D5 | SCHURTER

Linear/Saturating choke, THT, 0.5 mH, 8 A, DLFP-0125-08D5

Order No.: 59P8986
EAN: 4099889003345
MPN:
DLFP-0125-08D5
Series: DLFP
SCHURTER
DLFP-0125-08D5 SCHURTER Fixed Inductors
Image may differ
Unit Price (€ / pc.)
12.2570 € *
Available: 0 pcs.
Leadtime: 12 Weeks **
Total Price:
12.26 € *
*incl. VAT plus shipping costs
**Subject to prior sale
1 pcs.
12.2570 €

Linear/Saturating choke, DLFP-0125-08D5, SCHURTER

The DLFP-0125-08D5 is a linear/saturating choke that is used for energy storage in SMPS's. It is made of iron or metal powder cores with one winding.

Features

  • Linear/saturating choke
  • Flexible wire
  • Low noise development by using iron powder toroids instead of conventional iron lamination cores
  • Fully potted resign

Applications

  • Phase angle control circuits with thyristors, triacs or transistors
  • The choke acts at its optimum when it is mounted directly at the interference originator (thyristor, triac)
Technical specifications
Version Linear/Saturating choke
Design THT
Width 40 mm
DC current 8 A
DC resistance 54 mΩ
Height 30.8 mm
Inductance 0.5 mH
Length 40 mm
Logistics
Country of origin CH
Customs tariff number 85045000
MSL MSL 1
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
