DS1-20-0004 | SCHURTER
Storage choke, radial, 0.01 mH, DS1-20-0004
Unit Price (€ / pc.)
6.2475 € *
Available: 0 pcs.
Leadtime: 40 Weeks **
Total Price:
6.25 € *
Price list
Quantity
Price per unit*
1 pcs.
6.2475 €
10 pcs.
5.6882 €
50 pcs.
5.1170 €
100 pcs.
4.6053 €
*incl. VAT plus shipping costs
**Subject to prior sale
Storage choke, DS1-20-0004, SCHURTER
The DS1-20-0004 is a storage choke that is used for energy storage in SMPS's. It is made of iron or metal powder cores with one winding.
Features
- Storage choke
- Constant inductance at high alternating field modulation and large DC magnetization
- Reduced magnetic reversal
- THT-terminals
Applications
- Storage of energy in switched power supplies
- Switch-mode
- Chopper amplifiers
- DC drives and stepper motor controls
Technical specifications
| Ausführung | Speicherdrossel | |
| Bauform | radial | |
| Breite | 20 mm | |
| Gleichstromwiderstand | 8 mΩ | |
| Höhe | 15 mm | |
| Induktivität | 0.01 mH | |
| Länge | 20 mm | |
| Toleranz | ±15 % |
Download
Logistics
| Ursprungsland | CH |
| Zolltarifnummer | 85045000 |
| MSL | MSL 1 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
