DSH-14-0003 | SCHURTER
Storage choke, 0.012 mH, 2 A, DSH-14-0003
Unit Price (€ / pc.)
4.6529 € *
Available: 0 pcs.
Leadtime: 41 Weeks **
Total Price:
4.65 € *
Price list
Quantity
Price per unit*
1 pcs.
4.6529 €
10 pcs.
4.2364 €
50 pcs.
3.8080 €
100 pcs.
3.4272 €
*incl. VAT plus shipping costs
**Subject to prior sale
Storage choke, DSH-14-0003, SCHURTER
The DSH-14-0003 is a storage choke that is used for energy storage in SMPS's. It is made of iron or metal powder cores with one winding.
Features
- Storage choke
- Constant inductance at high alternating field modulation and large DC magnetization
- Inductor vertically positioned in housing
- Reduced magnetic reversal
Applications
- Storage of energy in switched power supplies
- Switch-mode
- Chopper amplifiers
- DC drives and stepper motor controls
Technical specifications
| Version | storage choke | |
| Width | 10.5 mm | |
| DC current | 2 A | |
| DC resistance | 25 mΩ | |
| Height | 13.5 mm | |
| Inductance | 0.012 mH | |
| Length | 15 mm | |
| Tolerance | ±15 % |
Download
Logistics
| Country of origin | LK |
| Customs tariff number | 85045000 |
| MSL | MSL 1 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
