DSH-22-0008 | SCHURTER
Storage choke, radial, 0.01 mH, 4.5 A, DSH-22-0008
Unit Price (€ / pc.)
3.8199 € *
Available: 0 pcs.
Leadtime: 40 Weeks **
Storage choke, DSH-22-0008, SCHURTER
The DSH-22-0008 is a storage choke that is used for energy storage in SMPS's. It is made of iron or metal powder cores with one winding.
Features
- Storage choke
- Constant inductance at high alternating field modulation and large DC magnetization
- Inductor vertically positioned in housing
- Reduced magnetic reversal
Applications
- Storage of energy in switched power supplies
- Switch-mode
- Chopper amplifiers
- DC drives and stepper motor controls
Technical specifications
| Ausführung | Speicherdrossel | |
| Bauform | radial | |
| Breite | 13 mm | |
| Gleichstrom | 4.5 A | |
| Gleichstromwiderstand | 8 mΩ | |
| Höhe | 24 mm | |
| Induktivität | 0.01 mH | |
| Länge | 23 mm | |
| Toleranz | ±15 % |
Download
Logistics
| Ursprungsland | LK |
| Zolltarifnummer | 85045000 |
| MSL | MSL 1 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
