3-103-778 | SCHURTER

IEC plug C14, 50 to 60 Hz, 4 A, 250 VAC, faston plug 6.3 mm, 3-103-778

Order No.: 75D0305
EAN: 4099891555276
MPN:
3-103-778
Series: DD14
SCHURTER
3-103-778 SCHURTER Interference suppression filter
Image may differ
Unit Price (€ / pc.)
40.3291 € *
Available: 9 pcs.
Leadtime: 11 Weeks **
Total Price:
40.33 € *
Price list
Quantity
Price per unit*
1 pcs.
40.3291 €
10 pcs.
35.4858 €
20 pcs.
34.5219 €
40 pcs.
33.5461 €
160 pcs.
31.6064 €
*incl. VAT plus shipping costs
**Subject to prior sale

IEC plug C14, 3-103-778, SCHURTER

Features

  • Ultra-compact design
  • Ideal for low profile designs
  • Aluminum case provides good shielding
  • Attractive flat design
  • Most compact power entry module with 2-stages filter
  • Fuseholder for fuse-links 5 x 20 mm

Applications

  • Ideal for application with high transient loads
  • Suitable for use in medical equipment
  • Suitable for appliances with protection class I
Technical specifications
ohmic resistance 1 MΩ
Connection faston plug 6.3 mm
Version IEC plug C14
Rated Voltage 250 VAC
integrated switch Yes
Capacity X|Y X 220 nF, Y1 1.5 nF, Y2 1 nF
max. frequency 60 Hz
max. operating temperature 85 °C
min. frequency 50 Hz
min. operating temperature -25 °C
With fuse Yes
Rated current 4 A
Logistics
Customs tariff number 85363010
Original Packaging Carton with 10 pieces
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
