Name: Microfuses 5 x 20 mm, 1.25 A, T, 300 V (DC), 250 V (AC), 1.5 kA breaking capacity, 0001.2505.G
Brand: SCHURTER
SKU: 59P1056
Price: 0.19 EUR
Availability: OutOfStock

Microfuses 5 x 20 mm, 1.25 A, T, 300 V (DC), 250 V (AC), 1.5 kA breaking capacity, 0001.2505.G

Order No.: 59P1056

EAN: 4099889101614

MPN:

0001.2505.G

Series: SPT 5x20

Image may differ

Key Specification:

Version microfuses

Design 5 x 20 mm

Enclosure ceramic tube

Rated current 1.25 A

Tripping characteristics T

Show 14 variants

Download Datasheet Technical specifications

Unit Price (€ / pc.)

0.1940 € *

Available: 0 pcs.

Leadtime: 20 Weeks **

Add to Cart

Total Price:

0.19 € *

*incl. VAT plus shipping costs

**Subject to prior sale

Description

Miniature fuse, 0001.2505.G, Schurter

Miniature Fuse, 5 x 20 mm, Time-Lag T, H, 250 VAC, UL: 115 V - 300 VDC

Applications

Primary Protection in Equipment
Power Supply Adapter for e.g. laptops
SMPS (Switching Mode Power Supply) for TV's and DVD's
