0034.6611 | SCHURTER
Micro fuse 8.5 x 8.5 mm, 400 mA, T, 63 V (DC), 250 V (AC), 35 A breaking capacity, 0034.6611
Unit Price (€ / pc.)
0.3570 € *
Available: 990 pcs.
Leadtime: 7 Weeks **
Total Price:
0.71 € *
Price list
Quantity
Price per unit*
2 pcs.
0.3570 €
10 pcs.
0.3094 €
50 pcs.
0.2773 €
100 pcs.
0.2440 €
*incl. VAT plus shipping costs
**Subject to prior sale
Micro fuse, 0034.6611, SCHURTER
Subminiature Fuse, 8.5 mm, Time-Lag T, 250 VAC, 63 VDC
Features
- Directly solderable on printed circuit boards
- Low Breaking Capacity
Technical specifications
| Ausführung | Kleinstsicherung | |
| Auslösecharakteristik | T | |
| Ausschaltvermögen | 35 A | |
| Bauform | 8,5 x 8,5 mm | |
| Durchmesser | 8.5 mm | |
| Höhe | 8.5 mm | |
| Nennspannung (AC) | 250 V | |
| Nennspannung (DC) | 63 V | |
| Nennstrom | 400 mA |
Download
Logistics
| Ursprungsland | CH |
| Zolltarifnummer | 85361010 |
| MSL | MSL 1 |
| Originalverpackung | Beutel mit 100 Stück |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
