3402.0010.11 | SCHURTER
SMD-Fuse 7.4 x 3.1 mm, 1.25 A, F, 63 V (DC), 63 V (AC), 50 A breaking capacity, 3402.0010.11
Unit Price (€ / pc.)
0.3808 € *
Available: 0 pcs.
Leadtime: 6 Weeks **
SMD-Fuse, 3402.0010.11,SCHURTER
The 3402.0010.11 is a quick-acting surface mount fuse with that is designed to protect less sensitive components and is also used to protect cabling from melting or catching fire when an overload occurs.
Features
- Material thermoplastic
- Material terminals copper alloy tin-plated
- High breaking capacity
- PCB or SMT mountable
Technical specifications
| Ausführung | SMD-Sicherung | |
| Auslösecharakteristik | F | |
| Ausschaltvermögen | 50 A | |
| Bauform | 7,4 x 3,1 mm | |
| Breite | 3.1 mm | |
| Gehäuse | SMD | |
| Höhe | 2.6 mm | |
| Länge | 7.4 mm | |
| Nennspannung (AC) | 63 V | |
| Nennspannung (DC) | 63 V | |
| Nennstrom | 1.25 A |
Download
Logistics
| Ursprungsland | CH |
| Zolltarifnummer | 85361010 |
| Originalverpackung | Rolle mit 100 Stück |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
