3403.0156.24 | SCHURTER
SMD-Fuse 3 x 10.1 mm, 100 mA, T, 125 V (DC), 250 V (AC), 200 A breaking capacity, 3403.0156.24
Unit Price (€ / pc.)
0.6426 € *
Available: 540 pcs.
Leadtime: 7 Weeks **
Total Price:
6.43 € *
Price list
Quantity
Price per unit*
10 pcs.
0.6426 €
100 pcs.
0.5831 €
500 pcs.
0.5593 €
2000 pcs.
0.5236 €
4000 pcs.
0.4760 €
*incl. VAT plus shipping costs
**Subject to prior sale
SMD-Fuse, 3403.0156.24, SCHURTER
The 3403.0156.24 is a SMT fuse. It is a time-lag fuse and can be directly solderable on printed circuit boards.
Features
- Material housing thermoplastic
- Material terminals copper alloy, tin-plated
- Suitable for reflow and wave soldering
- Vibration resistant
Applications
- Primary protection on SMD PCB-s
- AC and DC applications
Technical specifications
| Ausführung | SMD-Sicherung | |
| Auslösecharakteristik | T | |
| Ausschaltvermögen | 200 A | |
| Bauform | 3 x 10,1 mm | |
| Breite | 3 mm | |
| Gehäuse | SMD | |
| Höhe | 3 mm | |
| Länge | 10.1 mm | |
| Nennspannung (AC) | 250 V | |
| Nennspannung (DC) | 125 V | |
| Nennstrom | 100 mA |
Download
Logistics
| Ursprungsland | CH |
| Zolltarifnummer | 85361010 |
| MSL | MSL 1 |
| Originalverpackung | Blister mit 2.000 Stück |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
