8020.5068.G | SCHURTER
Microfuse 6.3 x 32 mm, 1 A, F, 500 V (DC), 500 V (AC), 1.5 kA breaking capacity, 8020.5068.G
Unit Price (€ / pc.)
0.6307 € *
Available: 0 pcs.
Leadtime: 19 Weeks **
Total Price:
0.63 € *
Price list
Quantity
Price per unit*
1 pcs.
0.6307 €
10 pcs.
0.5712 €
50 pcs.
0.5117 €
100 pcs.
0.4522 €
*incl. VAT plus shipping costs
**Subject to prior sale
Micro fuse, 8020.5068.G, SCHURTER
The 8020.5068.G is a quick-acting cartridge fuse that allows for a temporary current surge without going above the fuse's current rating. Because of this time delay fuses are most commonly used to protect motor circuits.
Features
- Material ceramic tube
- Material endcaps copper alloy nickel-plated
- Suitable for mounting in fuseholder / clip
- High breaking capacity up to 1500 A
Applications
- 3-phase applications
- DC applications
- Frequency converter
- Power electronics
- Power supplies
Technical specifications
| Ausführung | Feinsicherung | |
| Auslösecharakteristik | F | |
| Ausschaltvermögen | 1.5 kA | |
| Bauform | 6,3 x 32 mm | |
| Durchmesser | 6.35 mm | |
| Gehäuse | Keramikrohr | |
| Länge | 31.8 mm | |
| Nennspannung (AC) | 500 V | |
| Nennspannung (DC) | 500 V | |
| Nennstrom | 1 A |
Download
Logistics
| Ursprungsland | CN |
| Zolltarifnummer | 85361010 |
| MSL | MSL 1 |
| Originalverpackung | Karton mit 1.000 Stück |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
